GRAND CENTRAL TERMINAL / MTA ADDITION

Location: New York, NY, USA
Typology: Transportation & Retail - Landmark
Scale: 5 Stories / 48 acre (total site)
Phase: Feasibility Studies
Involvement: Conceptual design option studies, BIM 3D design model, sectional & plan drawings, visualizations & presentation material.
Software: Revit (BIM), AutoCAD, Illustrator, Photoshop & Powerpoint.


689 5TH ave

Beyer Blinder Belle

689-691 FIFTH AVENUE STOREFRONT

Location: New York, NY, USA
Typology: High-End Retail - Alteration - Tenant: Lacoste
Scale: 2 Stories of Retail (15 Stories in total)
Phase: Feasibility Studies for LPC & client & Construction Documents.
Involvement: Redesign of retail storefront, signage & entrance. Review packages for Landmark Preservation Commission (LPC). DOB (CD) filing set.
Software: Rhinoceros, AutoCAD, Photoshop & InDesign.


Beyer Blinder Belle

828-850 Madison Avenue - Exterior

Location: New York, NY, USA
Typology: High-End Retail - Alteration, Renovation & Restoration - Masterplan - Tenant: Cartier, Celine & Etc.
Scale: 2 Stories (36,000 SF)
Phase: Feasibility Studies for LPC & review packages & public hearings. client, Schematic Design, Design Development, Construction Documents, Bidding & Construction Administration.
Involvement: Redesign of entrance canopy & retail storefront. New design for exterior lightings & facade enclosures. A series of successful Landmark Preservation Commission (LPC) review packages & hearings.
Software: Rhinoceros, AutoCAD, InDesign, Photoshop & Word.


Beyer Blinder Belle

828-850 Madison Avenue - Interior

Location: New York, NY, USA
Typology: High-End Retail - Alteration, Renovation & Restoration - Masterplan - Tenant: Cartier, Celine & Etc.
Scale: 2 Stories (36,000 SF)
Phase: Feasibility Studies for LPC & client. Fast-Track (Schematic Design, Design Development, Construction Documents, Bidding & Construction Administration).
Involvement: Redesign & renovation of interior white box space. Coordination of new interior design layout with new perimeter window opening resulting from new exterior storefront on second floor. Detailing of new ceiling, window sill and wall enclosure. Fast track whole scope work including bidding phase, CA & official filing set with DOB & LPC. Approval of Landmark Preservation Commission (LPC).
Software: Rhinoceros, AutoCAD, InDesign, Photoshop & Word.


Beyer Blinder Belle

692-694 Broadway - Storefront

Location: New York, NY, USA
Typology: Retail - Alteration & Addition.
Scale: 1 Story
Phase: Feasibility studies
Involvement: Design option studies for new canopy & alteration of storefront. Site surveys & Landmark Preservation Commission (LPC) review packages.
Software: Rhinoceros, AutoCAD, InDesign & Photoshop.


Beyer Blinder Belle

26 W 17TH Street - Entrance

Location: New York, NY, USA
Typology: Retail - Alteration, Addition & Restoration.
Scale: 1 Story (2,200 SF)
Phase: Feasibility studies, Schematic Design, Design Development & Construction Documents.
Involvement: New design development of built-in shutter enclosure for entrance. Site visits & surveys. Development of alteration design strategies for existing entrance. Landmark Preservation Commission (LPC) review packages & hearings.
Software: Rhinoceros, AutoCAD, PowerPoint, InDesign & Photoshop.


Beyer Blinder Belle

111 Fifth Avenue - Accessibility & Signage

Location: New York, NY, USA
Typology: Retail - Alteration & Addition - Tenant: H&M
Scale: 1 Story
Phase: Feasibility Studies & Schematic Design.
Involvement: Design studies & development of accessibility and signage improvement to entrance. Storefront entrance alteration & new retail signage design. Landmark Preservation Commission (LPC) review packages.
Software: Rhinoceros, AutoCAD, InDesign & Photoshop.


Beyer Blinder Belle

680 Madison Avenue - Awning Alteration

Location: New York, NY, USA
Typology: Retail - Alteration
Scale: 1 Story
Phase: Post-Construction Revision
Involvement: Design revision of ground floor awnings, shop drawing revision mark-up, presentation and documentation submission to LPC for approval.
Software: AutoCAD, Microsoft Words, InDesign & Photoshop.


Beyer Blinder Belle

Pattison Place - Commercial Interior

Location: Philadelphia, PA, USA
Typology: Office - Interior
Scale: 11 Stories
Phase: Design Development.
Involvement: Design development and documentation of commercial office interior lobby space. 3D development, interior lobby common area calculation, materiality development and technical drawing set documentation and coordination in Revit for DD set.
Software: Revit (BIM), Microsoft Words, Powerpoint, InDesign & Photoshop.


Beyer Blinder Belle

Maritime Aquarium and Theater at Norwalk

Location: Norwalk, CT, USA
Typology: Mixed-Use, Theater & Aquarium Exhibit - Addition.
Scale: 2 Stories
Phase: Schematic Design, Design Development, Construction Documents, Bidding & Construction Administrations.
Involvement: BIM design development & documentation. Exterior & interior detail development & coordination with engineers, consultants & contractors. Bidding reviews, submittal (shop drawings & product data) reviews, RFIs, ASIs & Construction Administrations.
Software: Revit (BIM), AutoCAD, Rhinoceros, InDesign, Photoshop, Excel and Word.


Confidential Consulting Work

Govonor's Island - Buildg. 301 - Landmark Adpative-Reuse Renovation & Expansion

Location: Govonor's Island, New York, NY
Typology: Mixed-use Office & Landmark. Adaptive Re-use
Scale: 14,000 SF - 1 Stories (Exterior expansion & Interior Renovation)
Phase: Design Development (DD), Construction Documents (CD) & Bidding
Involvement: Landmark Adaptive Re-use Renovation & Expansion project. Responsible design development, detailed design and construction documents of exterior main design elements, such as south main entrance expansion and exterior enclosure designs for RTUs (Roof top units) and Ground MEP equipments. Responsible for architectural interior design developments, including, but not limited to, main entrance vestibule design, flood-gate enclosure design, main lobby design and coordination including the detailed elements such as interior enclosure detaills, including embedded locker design. Responsible for design management as well as coordination of external consultants and involvements in coordination calls with client and engineers.


Beyer Blinder Belle

Metropolitan Museum of Art - Security Design

Location: New York, NY, USA
Typology: Cultural & Landmark. Security & Accessibility Design Improvement.
Scale: City blocks - 5th Avenue between East 80th Street & East 84th Street.
Phase: Schematic Design & Design Development.
Involvement: Design option studies & development of new exterior security design. Site surveys. Development of new bollard design through coordination with landscape designer & structural engineer. Landmark Preservation Commission (LPC) review packages.
Software: Rhinoceros, Revit (BIM), AutoCAD, InDesign & Photoshop.


Beyer Blinder Belle

2551 Broadway - Residential Tower

Location: New York, NY, USA
Typology: Mixed-Use Residential Tower.
Scale: 22 Stories
Phase: Zoning Phase & Schematic Design.
Involvement: Zoning calculation and schematic design development in Revit. Preliminary drawing development and coordination with client.
Software: Revit (BIM), AutoCAD, InDesign & Photoshop.


Beyer Blinder Belle

14 Lecount Place - Residential Tower

Location: Greater New York Area, NY, USA
Typology: Mixed-Use Residential Tower.
Scale: 27 Stories / 380 Residential Units.
Phase: Construction Documents.
Involvement: Design development, coordination & documentation of exterior facade details through Building Information Modelling (BIM - Revit).
Software: Revit (BIM)


Beyer Blinder Belle

Greenwich Plaza / Train Station - Development

Location: Greenwich, CT, USA
Typology: Transit & Mixed-Use Addition.
Scale: 4 Stories
Phase: Feasibility Studies & City Planning Reviews.
Involvement: Architectural Board Planning drawing review set in AutoCAD. Exterior facade envelope development & documentation. 3D Design modelling in BIM.
Software: AutoCAD, Revit (BIM), Rhinoceros & InDesign.


Beyer Blinder Belle & Confidential

New Ground-Up - Feasibility Studies

Location: Greater New York Area, NY, USA & Greater Boston Area, MA, USA
Typology: Feasibility Studies.
Scale: Varies
Phase: Feasibility Studies. Conceptual Design. Zoning Studies.
Involvement: A series of feasibility & zoning envelope studies for new residential, office & mixed-use developments in the Greater New York area & Greater Boston area (Confidential). Massing studies, area breakdowns & visualizations.
Software: Rhinceros, AutoCAD, Excel, Photoshop & InDesign.


Robert A.M. Stern Architects

The Gayley at Wilshire - Residential Tower

Location: Los Angeles, CA, USA
Typology: Residential & Mixed-Use Retail
Scale: 29 Stories / 144 Units / 320,000 SF.
Phase: Schematic Design & Design Development.
Involvement: BIM design development & documentation. Exterior envelope detail development, coordination & documentation. Visualizations.
Software: Revit (BIM), V-ray Render, Enscape, Photoshop & InDesign.


Robert A.M. Stern Architects

555 W 22nd Street - Residential Development

Location: New York, NY, USA
Typology: Residential & Mixed-Use Retail
Scale: 26 Stories
Phase: Schematic Design.
Involvement: Schematic design development of residential tower complex development in BIM. Design studies, development & documentation of exterior podium envelope design, including large glass exterior canopy for atrium & drop-off, storefront & residential entry details.
Software: Revit (BIM), V-ray Rendering, Photoshop & InDesign.


with SMRT Inc.

1 Dimaond Street - New Development (Exterior & Interior)

Location: Portland, ME
Typology: Mid-rise Residential Building
Scale: 5 Stories
Phase: Conceptual Design & Schematic Design (SD)
Involvement: Creation of conceptual design, pricing package for developer, and development of subsequent schematic design set for midrise residential rental project. Creation of massing and unit-mix matrix for optimum and maximized rental development. Development of floor plans, coordination with landscape architects and various engineers. Development of facade envelope designs and floor plans.
Software: Rhinoceros and Revit (BIM).
